IMD-ERV35 II GD
Narrow back bar coolers – 1 glass door
ELECTRICAL | Cord and NEMA 5-15P plug, Electrical connection is 115V / 1ph / 60Hz. |
DOE | Hydrocarbon R-290 |
CAD & DOWNLOADS
Description
– AISI 430 stainless steel
– AISI 430 Stainless Steel
– Sealed interior fl oors
– CFC-Free polyurethane insulation, entire cabinet structure is foamed-in place using a high density polyurethane insulation
– Low GWP & Zero ODP eff ect
– (2) Two plastic coated wire shelves per section
– Self closing doors with stay open feature
– Stainless Steel heavy-duty hinges
– Triple chamber snap in door gaskets for easy removal and cleaning
– Doors locks
– Full-height door opening: WxH= 19-5/8”x26-7/8”
– Digital temperature controller with automatic defrost system
– Energy-saving non-electric condensate pan
– Evaporator coil coated with anti-corrosion material 100% Polyester
– Forced air refrigeration system
– Monoblock
– Interior LED lighting.
– AISI 430 Stainless Steel
– Sealed interior fl oors
– CFC-Free polyurethane insulation, entire cabinet structure is foamed-in place using a high density polyurethane insulation
– Low GWP & Zero ODP eff ect
– (2) Two plastic coated wire shelves per section
– Self closing doors with stay open feature
– Stainless Steel heavy-duty hinges
– Triple chamber snap in door gaskets for easy removal and cleaning
– Doors locks
– Full-height door opening: WxH= 19-5/8”x26-7/8”
– Digital temperature controller with automatic defrost system
– Energy-saving non-electric condensate pan
– Evaporator coil coated with anti-corrosion material 100% Polyester
– Forced air refrigeration system
– Monoblock
– Interior LED lighting.
Specifications
Specifications
![]() Width | ![]() Depth | ![]() Height | ![]() Doors | ![]() [ºF] | ![]() [ft 3 ] | ![]() [HP] | ![]() [Amps] 115V | ![]() [Lbs] | ![]() [$] |
|
---|---|---|---|---|---|---|---|---|---|---|
IMD-ERV15 II GD | 23-3/4 | 20-1/8 | 35-3/4 | 1 | 39ºF/54ºF | 5 | 1/6 | 3 | 152 | 3900 |
IMD-ERV25 II GD | 35-1/2 | 20-1/8 | 35-3/4 | 2 | 39ºF/54ºF | 8 | 1/5 | 3.4 | 202 | 4990 |
IMD-ERV35 II GD | 53-1/4 | 20-1/8 | 35-3/4 | 1 | 39ºF/54ºF | 5 | 1/6 | 3 | 284 | 6150 |
Cad & Revit files
